GC column, LIPODEX E, 50 m L, 0.25 mm ID, proprietary df

GC column, LIPODEX E, 50 m L, 0.25 mm ID, proprietary df
$2,010.00 * $0.00 * (0% Saved)

*taxes and shipping not included

Delivery time approx. 5 working days

723368.50 027010372010
Package unit 1 Piece(s)
Quantity:
Do you have any questions?
Please contact us.
Capillary columns for GC enantiomer separation. LIPODEX cyclodextrin phases are made of cyclic... more

Capillary columns for GC enantiomer separation. LIPODEX cyclodextrin phases are made of cyclic oligosaccharides consisting of six (α-cyclodextrin), seven (β-cyclodextrin) or eight (γ-cyclodextrin) glucose units bonded through α-1,4-linkages. Regioselective alkylation and/or acylation of the hydroxyl groups leads to lipophilic phases with varying enantioselectivity, which are well suited for chiral analyses. Important advantage - many compounds can be analyzed without derivatization (however, for certain substances enantioselectivity can be favorably influenced by formation of derivatives). A large number of separations have been achieved, however, it is not possible to make a general prediction, which phase could solve a given separation task. Even for compounds with small structural differences or within homologous series the enantiodifferentiation can be quite different.

Method Gas chromatography (GC)
Type GC column
Brand LIPODEX
Phase LIPODEX E
Composition Octakis-(2,6-di-O-pentyl-3-O-butyryl)-γ-cyclodextrin
USP listing Not available or proprietary
Polarity Not available or proprietary
Column inner diameter 0.25 mm
Film thickness Not available or proprietary
Column length 50 m
Recommended application(s) Alcohols, Alkyl halides, Amines, Diols, Enantiomers, Gas chromatography, GC, Hydroxycarboxylic acid esters, Ketones, Lactones, Pheromones (Cyclic acetals), α-amino acids
Tmax isotherm 200 °C
Tmax temp. program 220 °C
Housing type Wall coated open tubular (WCOT) capillary column, internal wall of capillary is coated with a very fine film of liquid stationary phase
Hardware Fused Silica coated with polyimide coiled/wound on metal cage
Cage size 7" (inch)
Integrated precolumn No
Storage temperature 15–25 °C / 59–77 °F
Scope of delivery 1x GC column coiled/wound on metal cage, user manual, certificate of analysis
Gross weight (incl. packaging) 261.2 g / 0.58 lbs
Packaging dimensions 240 x 214 x 69 mm / 9.45 x 8.43 x 2.72 Inch
Hazardous material No
