EC HPLC column (analytical), NUCLEODUR 100-5 CN-RP, 5 µm, 125x4 mm
*taxes and shipping not included
Delivery time approx. 5 working days
The endcapped cyanopropyl phase is based on high purity NUCLEODUR silica gel. This HPLC phase is able to generate a clearly recognizable different retention behavior compared to purely alkyl-functionalized surface modifications. The polarity can be classified as intermediate based on multiple retention mechanisms such as dipole-dipole, π-π, and also hydrophobic interactions. Therefore, this phase shows a distinct selectivity for polar organic compounds as well as for molecules containing π electron systems (e.g., analytes with double bonds). Cyanopropyl HPLC columns can be run in the RP mode using aqueous-organic eluent mixtures as well as in the NP mode, e.g., with hexane as mobile phase.
Method | HPLC, analytical |
Brand | NUCLEODUR |
Base material | NUCLEODUR - high purity silica |
Phase | NUCLEODUR 100-5 CN-RP |
USP listing | L10 |
Surface chemistry | Cyano, nitrile (CN) modification |
Mode | Multi-mode (NP and RP), Reversed phase (RP) |
Type | EC HPLC column (analytical) |
Hardware | Stainless steel |
Column length | 125 mm |
Column inner diameter | 4 mm |
Particle type | Fully porous particles (FPP) |
Particle shape | Spherical |
Particle size | 5 µm |
Eluent in HPLC column | Acetonitrile – water |
Recommended application(s) | HPLC, Normal phase, NP applications, Organic acids, Reversed phase, RP applications HPLC, Steroids, Tricyclic antidepressants |
Endcapped | Yes |
Carbon content | 7.0 % |
pH stability | 1.0–8.0 |
Pore size | 110 Å |
Specific surface according to BET | 340 m²/g |
Temperature stability (max) | 60 °C |
Pressure stability (max) | 600 bar / 8700 psi |
Column volume | 1.56 mL |
Storage temperature | 15–25 °C / 59–77 °F |
Scope of delivery | 1x analytical HPLC column, instruction leaflet, certificate of analysis |
Gross weight (incl. packaging) | 148.42 g / 0.33 lbs |
Packaging dimensions | 235 x 117 x 54 mm / 9.25 x 4.61 x 2.13 Inch |
Hazardous material | No |
