NucleoMag X32 – magnetic rod nucleic acid extraction system
The NucleoMag X32 is an automated platform for magnetic bead-based DNA/RNA extraction with a minimal benchtop footprint. Capable of processing up to 32 samples at one time, the stand-alone instrument is easy to set up, program, and operate. Mixing, magnetic bead transfer, washing, and elution steps are performed automatically, saving valuable hands-on time. The purification process can be completed within 20 to 60 minutes depending on the type of NucleoMag kit used and the complexity of the program.
- Fast, reliable and reproducible DNA / RNA extractions
- Process up to 32 samples in parallel
- Compact footprint (417 x 410 x 426 mm)
Nucleic acid extraction made easy with the NucleoMag X32!
For more information on technical data, please see section „Technical data & contact information"
Automation Benefits
Automating repetitive work processes can positively influence your work in many ways. Benefit from consistent, on-time output, reproducibility, standardization, increased hands-off time, and documented data integrity!
Discover the advantages of automation and explore MN’s extensive portfolio of automation solutions, including NucleoMag, NucleoSpin, and Protino. Our hands-free processing of a diverse range of samples at high throughput enables you to concentrate on other important tasks. We’re here to help you optimize your workflow and boost your productivity.
Contact us now to elevate your research with the power of MACHEREY-NAGEL. We support you every step of the way to automate your genomic workflow.
Technical data & contact information
NucleoMag X32
| Specification | Description |
| Display | 7.0 inch-color touch screen |
| Capacity | 1-32 samples |
| Sample volume | 50–1000 µL |
| Magnetic bead recovery rate | >95 % |
| Lysis temperature range | Ambient, 37 °C - 120 °C |
| Elution temperature range | Ambient, 37 °C - 120 °C |
| Mixing speed | Variable, 10 Levels |
| Operation | Touch screen |
| Program memory | 500 programs (internal memory) |
| Application | Automated extraction system for magnetic bead-based DNA/RNA purification |
| Internal lighting | LED |
| Contamination control | Internal UV lamp, purification filter system to reduce cross-contamination |
| Program transfer | Pre-installed script parameters for NucleoMag kits, USB flash drive |
| Dimensions | 417 x 410 x 426 mm |
| Weight | 30 kg |
| Power supply | 100–240 V AC |
| Warranty | 2 Year(s) |
You have questions about the device or want to learn more about suitable extraction reagents and consumables? Please contact us for assistance or to request more information about availability in your country.
Phone: +49 2421 969 0
